1-65
Introduction
Radio Ports
Table 1-6. Factory Default Settings for Radio Adoption Default Configurations
In the Web browser interface, you change these configurations from the
Network Setup > Radio Adoption Defaults screen, as described in Chapter 3:
Radio Port Configuration. You can then save these settings as customized
radio adoption default configurations.
If you make a change to the radio adoption default configuration, the change
only takes effect for newly adopted RPs.
The default configuration does not include WLAN assignments until you
manually enable one or more WLANs. With normal configuration, the radio
adoption default configuration always takes the settings shown in Table 1-7.
The module redeploys the new WLAN assignments every time that you enable
or disable a WLAN.
Setting 802.11a 802.11bg
Placement Indoors Indoors
Channel Random Random
Power Depends on country code Depends on country code
Rate settings (in Mbps) Basic: 6, 12, 24
Supported: 6, 9, 12, 18, 24, 36,
48, 54
Basic: 1, 2, 5.5, 11
Supported: 1, 2, 5.5, 6, 9, 11,
12, 18, 24, 36, 48, 54
Antenna mode Diversity Diversity
Maximum stations 64 64
RTS threshold (bytes) 2346 2346
Beacon interval (microseconds) 100 100
DTIM period (beacons) 2 2
Self healing offset 0 0
