A-18
ProCurve Wireless Services xl Module Command Line Reference
Manager Commands
• shutdown- Trace shutdown messages.
• states- Trace redundancy state machine messages.
• subagent - Trace subagent messages.
• timer- Trace timer handling messages.
• warnings- Trace warning messages.
Default Setting
N/A
Command Mode
Manager
Example
debug upd-server
This command traces update server debugging messages. The no command negates
the trace.
Syntax
debug upd-server (all | autoinstall | cli | espd | shim | subagent |)
• all- Trace all update server debugging messages.
• autoinstall - Trace auto-install debugging messages from the update sever.
• cli - Trace cli messages to/from the update sever.
• espd -Trace ESPd messages.
• shim- Trace shim debugging messages.
• subagent - Trace subagent messages.
Default Setting
N/A
Command Mode
Manager
ProCurve(wireless-services-B)#debug redundancy ccmsg
ProCurve(wireless-services-B)#
