A-20

ProCurve Wireless Services xl Module Command Line Reference

Manager Commands

Default Setting

N/A

Command Mode

Manager

Example

dir

This command displays list of available files on the filesystem.

Syntax

dir (all | recursive |) (DIR | all-filesystems |)

• all - Display all available files.

• recursive- Display recursive files.

• DIR- Display list of all available files in the file path.

• all-filesystems - Display list of all available filesystems.

Default Setting

N/A

Command Mode

Manager

ProCurve(wireless-services-B)#diff TESTFILE TESTFILE2

--- TESTFILE

+++ TESTFILE2

@@ -1 +1 @@

-testing edit, view, and delete file.

+testing edit, erase, and contents of file.

ProCurve(wireless-services-B)#
