A-22

ProCurve Wireless Services xl Module Command Line Reference

Manager Commands

edit

This command edits an existing file or creates a new text file.

Syntax

edit FILE

• FILE -Name of file to edit or create.

Default Setting

N/A

Command Mode

Manager

Example

ProCurve(wireless-services-B)#edit TESTFILE

GNU nano 1.2.4 File: TESTFILE

testing edit, erase, and view file

[ New File ]

^G Get Help ^O WriteOut ^R Read File ^Y Prev Page ^K Cut Text ^C Cur Pos

^X Exit ^J Justify ^W Where Is ^V Next Page ^U UnCut Txt ^T To Spell

[PRESS CNTRL X}

-------------------------------------------------------------------

Save modified buffer (ANSWERING "No" WILL DESTROY CHANGES) ?Y

Y Yes

N No ^C Cancel

-------------------------------------------------------------------

File Name to Write: TESTFILE [PRESS ENTER]

^G Get Help M-P Prepend

M-A Append ^C Cancel

-------------------------------------------------------------------

testing edit, erase, and view file

[ Wrote 1 line ]

ProCurve(wireless-services-B)#
