A-23

ProCurve Wireless Services xl Module Command Line Reference

Manager Commands

erase

This command deletes a specified file from the system.

Syntax

erase FILE

• FILE- Name of the specified file to be deleted.

– FILES:

+ flash:/path/file

+ startup-config - Resets configuration back to factory default.

Default Setting

N/A

Command Mode

Manager

Example

exit

This command sets the current command level to the previous command level.

Syntax

exit

Default Setting

N/A

Command Mode

Manager

ProCurve(wireless-services-B)#erase startup-config

Startup config is deleted. Please reload the wireless module

for factory default configuration to take effect.

ProCurve(wireless-services-B)#

ProCurve(wireless-services-B)#erase TESTFILE

ProCurve(wireless-services-B)#
