A-27

ProCurve Wireless Services xl Module Command Line Reference

Manager Commands

• debug - Debug functions. To access individual debug commands, begin

with the basic command

“debug all” on page A-11.

• page - Toggle paging. See “page” on page A-27.

• show - Show commands. To access individual show commands, “debug

all” on page A-11.

Default Setting

N/A

Command Mode

Manager

Example

page

This command enables pausing of output to the screen. The no command disables

the pausing of the output.

Syntax

page

Default Setting

N/A

Command Mode

Manager

Example

ping

This command sends ICMP echo request packets to another node on the network.

Syntax

ProCurve(wireless-services-B)#no debug cc

ProCurve(wireless-services-B)#

ProCurve(wireless-services-B)#page

ProCurve(wireless-services-B)#
