Wireless/Redundant Edge Services xl Module Management and Configuration Guide WS.02.xx and greater

A-28
ProCurve Wireless Services xl Module Command Line Reference
Manager Commands
ping WORD
• WORD - Hostname or IP address of the host.
Default Setting
N/A
Command Mode
Manager
Command Usage
• Use the ping command to see if another site on the network can be reached.
• The following are some results of the ping command:
– Normal response - The normal response occurs in one to ten seconds,
depending on network traffic.
– Destination does not respond - If the host does not respond, an error is
returned with statistics on the attempted communication.
– Destination unreachable - The gateway for this destination indicates
that the destination is unreachable.
– Network or host unreachable - The gateway found no corresponding
entry in the route table.
Example
pwd
This command displays the current directory.
Syntax
pwd
Default Setting
N/A
ProCurve(wireless-services-B)#ping 10.1.0.9
PING 10.1.0.9 (10.1.0.9): 100 data bytes
108 bytes from 10.1.0.9: icmp_seq=0 ttl=64 time=2.1 ms
108 bytes from 10.1.0.9: icmp_seq=1 ttl=64 time=1.2 ms
108 bytes from 10.1.0.9: icmp_seq=2 ttl=64 time=0.7 ms
108 bytes from 10.1.0.9: icmp_seq=3 ttl=64 time=1.5 ms
108 bytes from 10.1.0.9: icmp_seq=4 ttl=64 time=1.1 ms
--- 10.1.0.9 ping statistics ---
5 packets transmitted, 5 packets received, 0% packet loss
round-trip min/avg/max = 0.7/1.3/2.1 ms
ProCurve(wireless-services-B)#
