A-29

ProCurve Wireless Services xl Module Command Line Reference

Manager Commands

Command Mode

Manager

Example

reload

This command halts and performs a warm reboot.

Syntax

reload

Default Setting

N/A

Command Mode

Manager

Example

rename

This command renames a file.

Syntax

rename FILE

• FILE - File to be renamed.

– FILE - New file name.

Default Setting

N/A

ProCurve(wireless-services-B)#pwd

flash:/

ProCurve(wireless-services-B)#

ProCurve(wireless-services-B)#reload

Wireless module will be rebooted, do you want to continue?

(y/n): y

Do you want to save current configuration? (y/n):y

ProCurve(config)#
