A-30

ProCurve Wireless Services xl Module Command Line Reference

Manager Commands

Command Mode

Manager

Example

To validate the name change, use the DIR command.

rmdir

This command deletes a directory.

Syntax

rmdir DIR

• DIR - Directory to be deleted.

Default Setting

N/A

Command Mode

Manager

ProCurve(wireless-services-B)#rename TESTFILE3 TESTFILE2

ProCurve(wireless-services-B)#

ProCurve(wireless-services-B)#dir

Directory of flash:/

drwx 1024 Tue Oct 1 00:14:16 2002 hotspot

drwx 1024 Thu Feb 16 15:37:09 2006 crashinfo

drwx 80 Fri Feb 17 12:48:10 2006 log

drwx 1024 Fri Feb 17 09:48:19 2006 TESTDIR

-rw- 43 Fri Feb 17 10:19:52 2006 TESTFILE2

-rw- 37 Fri Feb 17 10:20:47 2006 TESTFILE

ProCurve(wireless-services-B)#
