A-31

ProCurve Wireless Services xl Module Command Line Reference

Manager Commands

Example

To validate the directory is deleted, use the DIR command.

telnet

This command opens a telnet connection.

Syntax

telnet WORD

• WORD - IP address or hostname of a remote system.

– PORT - TCP Port number.

Default Setting

N/A

Command Mode

Manager

Example

This example displays an incomplete route telnet message.

ProCurve(wireless-services-B)#rmdir TESTDIR

ProCurve(wireless-services-B)#

ProCurve(wireless-services-B)#dir

Directory of flash:/

drwx 1024 Tue Oct 1 00:14:16 2002 hotspot

drwx 1024 Thu Feb 16 15:37:09 2006 crashinfo

drwx 80 Fri Feb 17 12:48:10 2006 log

-rw- 43 Fri Feb 17 10:19:52 2006 TESTFILE2

-rw- 37 Fri Feb 17 10:20:47 2006 TESTFILE

ProCurve(wireless-services-B)#

ProCurve(wireless-services-B)#telnet 10.1.0.9 23

telnet: Unable to connect to remote host (10.1.0.9): No

route to host

ProCurve(wireless-services-B)#
