A-32

ProCurve Wireless Services xl Module Command Line Reference

Manager Commands

terminal

This command sets terminal line parameters.

Syntax

terminal length | width

• length - Set number of lines on a screen.

– <2-1000> - Number of lines on a screen.

• width - Set width of display terminal.

– <61-1920> - Number of characters on a screen line.

Default Setting

N/A

Command Mode

Manager

Example

upgrade

This command upgrades the software image.

Syntax

upgrade URL

• URL - Location of firmware image.

– URLs: tftp://<hostname or IP>/path/file

ftp://<user>:<passwd>@<hostname or IP>/path/file

Default Setting

N/A

Command Mode

Manager

ProCurve(wireless-services-B)#terminal length 1000

ProCurve(wireless-services-B)#

ProCurve(wireless-services-B)#terminal width 1900

ProCurve(wireless-services-B)#
