A-33

ProCurve Wireless Services xl Module Command Line Reference

Manager Commands

Example

upgrade-abort

This command aborts an ongoing upgrade.

Syntax

upgrade-abort

Default Setting

N/A

Command Mode

Manager

Example

write

This command writes the running configuration to memory or terminal.

Syntax

write memory | terminal

• memory - Write to NV memory.

• terminal - Write to terminal.

Default Setting

N/A

Command Mode

Manager

ProCurve(wireless-services-B)#upgrade tftp://192.168.1.10/

WS.00.01.img

ProCurve(wireless-services-B)#

ProCurve(wireless-services-B)#upgrade-abort

ProCurve(wireless-services-B)#
