A-36

ProCurve Wireless Services xl Module Command Line Reference

Global Commands

boot

This command reboots the wireless module.

Syntax

boot flash (primary | secondary )

• flash - Specifies the boot image to use after reboot.

– primary - Primary image.

– secondary - Secondary image.

Default Setting

N/A

Command Mode

Global Configuration

Example

country-code

This command configures the country of operation. All existing radio configuration

will be erased.

Syntax

country <country_code>

• country_code - A two character code that identifies the country of operation.

See

Table A-1 on page A-37 for a full list of the codes.

ProCurve(wireless-services-B)#configure

ProCurve(wireless-services-B)(config#boot flash primary

Wireless module will be rebooted, do you want to continue?

(y/n): y

Do you want to save current configuration? (y/n):n

ProCurve(config)#
