A-38

ProCurve Wireless Services xl Module Command Line Reference

Global Commands

crypto

This command configures encryption related parameters.

Syntax

crypto pki (enroll | trustpoint )

• crypto pki - Configures public key infrastructure commands.

– enroll - Request a certificate from a CA.

+ local - CA server name.

– trustpoint- Define a CA trustpoint.

+ local - CA server name.

Default Setting

N/A

Command Mode

Global Configuration

Example

end

This command ends the current mode and changes to the Manager mode.

Syntax

end

Default Setting

N/A

Command Mode

Global Configuration

ProCurve(wireless-services-B)#configure

ProCurve(wireless-services-B)(config)#crypto pki trustpoint

local

ProCurve(wireless-services-B)(config)#
