A-41
ProCurve Wireless Services xl Module Command Line Reference
Global Commands
Syntax
interface (IFNAME)
no interfaces
• IFNAME - Specifies interfaces (vlan1 - vlan4094).
Default Setting
N/A
Command Mode
Global Configuration
Example
ip (global)
This command configures ip parameters.The no command negates this configuration.
Syntax
ip (default-gateway | dns | dns-lookup | domain | route | routing | web-manage-
ment)
no ip
• default-gateway - Configures a default gateway.
– A.B.C.D - IP gateway address.
• dns - Adds a Nameserver to the DNS.
– A.B.C.D - IP address of the Nameserver to add.
• dns-lookup - Enables Domain Name Service (DNS).
• domain - Sets default domain for DNS.
– WORD - Domain string (e.g. company.com).
• route - Establishes static routes.
– A.B.C.D - IP destination prefix.
+ A.B.C.D - IP destination prefix mask.
+ A.B.C.D - IP gateway address.
– A.B.C.D/M - IP destination prefix.(e.g. 10.0.0.0/8)
+ A.B.C.D - IP gateway address.
ProCurve(wireless-services-B)#configure
ProCurve(wireless-services-B)(config)#interface vlan1
ProCurve(wireless-services-B)(config-if)#
