A-42
ProCurve Wireless Services xl Module Command Line Reference
Global Commands
• routing - Turns on IP routing.
• web-management - Configures web server.
Default Setting
N/A
Command Mode
Global Configuration
Example
Related Commands
show ip (page A-89)
licenses
This command configures licensing parameters.
Syntax
licenses (hardware-id | install | uninstall)
• hardware-id - Generates a hardware ID for license registration purposes.
– radio-ports - Feature group.
• install - Installs the specified license key.
– radio-ports - Feature group.
+ WORD - License key: 44 byte char string encrypted with hardware ID.
• uninstall - Uninstall a set of licenses previously installed on the blade.
– radio-ports - Feature group.
+ <0-10000> - Value of the license to be uninstalled (e.g. number of radio
ports).
Default Setting
N/A
ProCurve(wireless-services-B)#configure
ProCurve(wireless-services-B)(config)#ip route 10.0.0.1/4
255.255.255.0
ProCurve(wireless-services-B)(config)#ip routing
ProCurve(wireless-services-B)(config)#ip web-management
ProCurve(wireless-services-B)(config)#
