A-44
ProCurve Wireless Services xl Module Command Line Reference
Global Commands
• facility - Sets syslog facility in which log messages are sent.
– local0 - Syslog facility local0.
– local1 - Syslog facility local1.
– local2 - Syslog facility local2.
– local3 - Syslog facility local3.
– local4 - Syslog facility local4.
– local5 - Syslog facility local5.
– local6 - Syslog facility local6.
– local7 - Syslog facility local7.
• host - Configures remote host to receive log messages.
– A.B.C.D - Remote host’s IP address.
• on - Enables logging of system messages.
Default Setting
N/A
Command Mode
Global Configuration
Example
Related Commands
show logging (page A-91)
password-encryption
This command encrypts passwords in configuration. The no command negates the
encryption.
Syntax
password-encryption (secret)
no password-encryption
• secret - Encrypts passwords with secret phrase.
– 2 - Type of encryption SHA256-AES256.
+LINE - Passphrase for encryption.
ProCurve(wireless-services-B)#configure
ProCurve(wireless-services-B)(config)#logging facility
local0
ProCurve(wireless-services-B)(config)#logging buffered
alerts
ProCurve(wireless-services-B)(config)#
