A-45
ProCurve Wireless Services xl Module Command Line Reference
Global Commands
Default Setting
Disabled
Command Mode
Global Configuration
Example
Related Commands
show password-encryption (page A-92)
redundancy
This command configures redundancy group parameters. The no negates the config-
uration.
Syntax
redundancy (discovery-period | enable | group-id | handle-stp | heartbeat-period
| hold-period | interface-ip | member-ip | mode)
no redundancy
• discovery-period - Sets the redundancy discovery interval.
– <10-60> - Discovery time in secs (default is 30).
• enable - Enable redundancy protocol.
• group-id - Sets the redundancy group ID.
– <1-65535> - Redundancy group ID.
• handle-stp - Delays the redundancy protocol state machine exec, consid-
ering STP.
– enable - Sets handle-stp to true.
• heartbeat-period - Sets the redundancy heartbeat interval.
– <1-255> - Heartbeat interval in secs (default is 5).
• hold-period - Sets the redundancy hold interval.
– <10-255> - Hold interval in secs (default is 15).
• interface-ip - Sets redundancy interface IP address.
– <A.B.C.D> - IP address of the wireless module.
ProCurve(wireless-services-B)#configure
ProCurve(wireless-services-B)(config)#password-encryption
secret 2 pass
ProCurve(wireless-services-B)(config)#
