A-46
ProCurve Wireless Services xl Module Command Line Reference
Global Commands
• member-ip - Adds member to this redundancy group.
– <A.B.C.D> - IP address of the member.
• mode - Sets the redundancy mode.
– active - Mode can be active.
– standby - Mode can be standby.
Default Setting
Disabled
Command Mode
Global Configuration
Example
Related Commands
show redundancy (page A-93)
ProCurve(wireless-services-B)#configure
ProCurve(wireless-services-B)(config)#redundancy interface-
ip 10.10.1.20
ProCurve(wireless-services-B)(config)#redundancy member-ip
10.10.1.21
ProCurve(wireless-services-B)(config)#redundancy mode active
ProCurve(wireless-services-B)(config)#redundancy hold-period
20
ProCurve(wireless-services-B)(config)#redundancy group-id 50
ProCurve(wireless-services-B)(config)#redundancy handle-stp
enable
ProCurve(wireless-services-B)(config)#redundancy discovery-
period 10
ProCurve(wireless-services-B)(config)#redundancy hold-period
10
ProCurve(wireless-services-B)(config)#
