A-51
ProCurve Wireless Services xl Module Command Line Reference
Global Commands
sntp
This command configures simple NTP. The no command negates this configuration.
Syntax
sntp (enable | server1 | sever2 | server3)
no sntp
• enable - Enables time synchronization with Simple NTP servers.
• server1 - Configures first SNTP server.
– A.B.C.D - IP address of first SNTP server.
• server2 - Configures second SNTP server.
– A.B.C.D - IP address of second SNTP server.
• server3 - Configures first SNTP server.
– A.B.C.D - IP address of third SNTP server.
Default Setting
Disabled
Command Mode
Global Configuration
Example
Related Commands
show sntp (page A-100)
time
This command configures time parameters.
Syntax
time
• HH:MM:SS - Current Time (in military format hours, minutes, and seconds).
Default Setting
Enabled
ProCurve(wireless-services-B)#configure
ProCurve(wireless-services-B)(config)#sntp server1 10.10.1.0
ProCurve(wireless-services-B)(config)#
