A-55
ProCurve Wireless Services xl Module Command Line Reference
Interface Commands
Interface Commands
These commands are used to configure the Interface Context commands.
description (interface)
This command configures a description for the interface. The no command negates
this configuration.
Syntax
description (LINE )
no description
• LINE - Characters describing this interface.
Default Setting
N/A
Command Mode
Interface Configuration
Command Function Page
[no] description (Negates) Interface specific description. A-55
end Detailed in Global Command Section. A-38
exit Detailed in Manager Command Section. A-23
help Detailed in Manager Command Section A-24
[no] ip (Negates) Sets the IP address of the interface. A-56
logout Detailed in Manager Command Section A-25
management Sets current interface as Management Interface. A-57
[no] mtu (Negates) Sets mtu value for vlan interface. A-57
show Detailed in Show Command Section A-83
support Detailed in Support Command Section A-131
