A-57
ProCurve Wireless Services xl Module Command Line Reference
Interface Commands
management
This command configures the selected interface as the management interface.
Syntax
management
Default Setting
N/A
Command Mode
Interface Configuration
Example
Related Commands
show management (page A-92)
mtu
This command sets the mtu value for the vlan interface.
Syntax
mtu (<512-1500>)
• <512-1500> - MTU in bytes.
Default Setting
N/A
Command Mode
Interface Configuration
ProCurve(wireless-services-B)#configure
ProCurve(wireless-services-B)(config)#interface vlan1
ProCurve(wireless-services-B)(config-if)#management
ProCurve(wireless-services-B)(config-if)#
