A-62

ProCurve Wireless Services xl Module Command Line Reference

Wireless Commands

Syntax

ap-detection (approved | enable | max-aps | timeout )

no ap-detection

• approved - Configures the approved detection list.

– add - Add an entry to the approved AP list .

+<1-200> - Index where this approved entry will be added: <1-200>.

- MAC - MAC address in AA-BB-CC-DD-EE-FF format.

++LINE - A string of up to 32 characters.

++any - Any SSID.

- any - Any MAC address.

++LINE - A string of up to 32 characters.

++any - Any SSID.

• enable - Allow radio-ports to look for APs.

• max-aps - The maximum amount of entries unapproved-seen and approved-

seen can show.

– <1-1000> - Number of entries between 1 and 1000.

• timeout - The amount of seconds a AP will remain in the list after it is no

longer seen.

– <1-65535> - Number of seconds between 1 and 65535.

Default Setting

Disabled

Command Mode

Wireless Configuration

Example

ProCurve(wireless-services-B)#configure

ProCurve(wireless-services-B)(config)#wireless

ProCurve(wireless-services-B)(config-wireless)#ap-detection

approved add 2 any any

ProCurve(wireless-services-B)(config-wireless)#ap-detection

enable

ProCurve(wireless-services-B)(config-wireless)#ap-detection

timeout 65

ProCurve(wireless-services-B)(config-wireless)#ap-detection

max-aps 200

ProCurve(wireless-services-B)(config-wireless)#
