A-64
ProCurve Wireless Services xl Module Command Line Reference
Wireless Commands
• excessive-associations - Monitors the number of association requests from
stations.
– <0-65535> - Maximum number of association requests per second .
• excessive-probes - Monitors the number of probe requests from stations.
– <0-65535> - Maximum number of association requests per second .
• filter-ageout - Set the number of seconds to filter a station that set
off IDS.
– <0-65535> - Time in seconds.
Default Setting
N/A
Command Mode
Wireless Configuration
Example
Related Commands
show wireless ids (page A-110)
mac-auth-local
This command configures the local MAC authentication list. The no command
disables the configuration.
Syntax
mac-auth-local
no mac-auth-local
• <1-1000> - MAC Auth local entry.
– allow - Allow stations that match this rule to associate.
ProCurve(wireless-services-B)#configure
ProCurve(wireless-services-B)(config)#wireless
ProCurve(wireless-services-B)(config-wireless)#ids
excessive-associations 500
ProCurve(wireless-services-B)(config-wireless)#ids
excessive-probes 400
ProCurve(wireless-services-B)(config-wireless)#ids filter
ageout 40
ProCurve(wireless-services-B)(config-wireless)#
