A-66
ProCurve Wireless Services xl Module Command Line Reference
Wireless Commands
Example
radio
This command configures the radio parameters. The no command negates the radio
parameter configuration.
Note To configure many of the radio parameters, you must first configure the country code.
See country code.
Syntax
radio ( <1-1000> | RADIO | add | all-11a | all-11bg | configure-8021X | default-11a
| default-11bg )
no radio
• <1-1000> - A single radio index.
• RADIO - A list (eg: 1,3,7) or range (eg: 3-7) of radio indices.
• all-11a - All 11a radios currently in configuration.
• all-11bg - All 11bg radios currently in configuration.
• default-11a - Default 11a configuration template.
• default-11bg - Default 11bg configuration template.
The radio (<1-1000> | RADIO | all-11a | all-llbg | default-11a | default-11bg)
commands share the following parameters:
– adoption-pref-id - A preference identifier for this radio port. The radio
port is more likely to be adopted by a wireless module that
is its preferred wireless module.
+<1-65535> - The ID.
– antenna-mode - Antenna diversity mode.
+diversity - Full Diversity (both antennas).
+primary - Primary Antenna only.
+secondary - Secondary Antenna only.
– beacon-interval - Beacon interval in K-uSec.
+<50-200> - Beacon interval in milliSeconds.
ProCurve(wireless-services-B)#configure
ProCurve(wireless-services-B)(config)#wireless
ProCurve(wireless-services-B)(config-wireless)#proxy-arp
enable
ProCurve(wireless-services-B)(config-wireless)#
