A-70
ProCurve Wireless Services xl Module Command Line Reference
Wireless Commands
Example
Related Commands
show wireless radio-statistics (page A-113)
self-heal
This command configures the self-healing commands. The no command negates the
configuration.
Syntax
self-heal (interference-avoidance| neighbor-recovery)
no self-heal
ProCurve(wireless-services-B)#configure
ProCurve(wireless-services-B)(config)#wireless
ProCurve(wireless-services-B)(config-wireless)#radio 1
adoption-pref-id 5
ProCurve(wireless-services-B)(config-wireless)#radio 1
antenna-mode diversity
ProCurve(wireless-services-B)(config-wireless)#radio 1
beacon-interval 50
ProCurve(wireless-services-B)(config-wireless)#radio 1
channel-power indoor acs 10
Regulatory parameter values depend on country of operation and radio
type.Refer to documentation for more regulatory information.
ProCurve(wireless-services-B)(config-wireless)#radio 2 copy
config-from default-11a
ProCurve(wireless-services-B)(config-wireless)#radio 1 max-
stations 64
ProCurve(wireless-services-B)(config-wireless)#radio 1 wmm
background cw 3 5
ProCurve(wireless-services-B)(config-wireless)#radio add 5
A1-B2-C3-D4-E5-F6 11bg
ProCurve(wireless-services-B)(config-wireless)#radio
configure-8021X username manager password simple
