A-72
ProCurve Wireless Services xl Module Command Line Reference
Wireless Commands
Example
Related Commands
show wireless self-heal-config (page A-120)
wlan
This command configures the wireless LAN parameters. The no command negates
the WLAN parameter configuration.
Syntax
wlan ( <1-32> | WLAN )
no wlan
• <1-1000> - A single WLAN index.
• WLAN - A list (eg: 1,3,7) or range (eg: 3-7) of WLAN indices.
The radio (<1-1000> | WLAN ) commands share the following parameters:
– authentication-type - The authentication type of this WLAN.
+eap - EAP authentication (802.1X).
+none - None / pre-shared keys.
+web-auth - Web based authentication (Note: encryption-type will be
changed to none).
– closed-system - Hides the SSID in beacons, and doesn’t respond to
probes for broadcast ESS on this WLAN.
– description - The description of this WLAN.
+LINE - A string of up to 20 characters.
ProCurve(wireless-services-B)#configure
ProCurve(wireless-services-B)(config)#wireless
ProCurve(wireless-services-B)(config-wireless)#self-heal
interference-avoidance enable
ProCurve(wireless-services-B)(config-wireless)#self-heal
neighbor-recovery enable
ProCurve(wireless-services-B)(config-wireless)#self-heal
neighbor-recovery neighbors 5 5
ProCurve(wireless-services-B)(config-wireless)#self-heal
neighbor-recovery run-neighbor-detect
ProCurve(wireless-services-B)(config-wireless)#
