A-73

ProCurve Wireless Services xl Module Command Line Reference

Wireless Commands

– dot11i - Configures IEEE 802.11i (TKIP/AES) parameters.

+key - Configures the key (PMK).

-0 - Password is specified UNENCRYPTED.

++WORD - The 256 bit (64 hex characters) long key.

-2 - Password is encrypted with password-encryption secret.

++WORD - The 256 bit (64 hex characters) long key.

-WORD - The 256 bit (64 hex characters) long key.

+key-rotation - Controls the periodic update of the broadcast keys of

all associated stations.

-enable - Enables key rotation.

+key-rotation-interval - Configures the broadcast key rotation interval.

-<60-86400> - The key rotation interval in seconds.

+oo-pmk-caching - Enables the opportunistic use of cached pairwise

master keys (fast roaming with eap/802.1X).

+phrase - Configures the passphrase.

- 0 - Password is specified UNENCRYPTED.

++LINE - A passphrase between 8 and 63 characters long.

- 2 - Password is encrypted with password-encryption secret.

++LINE - A passphrase between 8 and 63 characters long.

- LINE - A passphrase between 8 and 63 characters long.

+pmk-caching - Enables the use of cached pairwise master keys (fast

roaming with eap/802.1X.

– enable - Enables specified wireless LAN(s).

– encryption-type - Enables specified wireless LAN(s).

+aes - AES Counter Mode CBC-MAC Protocol (CCMP).

+none - No encryption.

+tkip - Temporal Key Integrity Protocol (TKIP).

+tkip-aes - Enables both TKIP and AES on this WLAN.

+wep128 - Wired Equivalence Privacy (WEP) with 128 bit keys.

+wep64 - Wired Equivalence Privacy (WEP) with 64 bit keys.

Note A configuration where two WLANs are mapped to the same VLAN, and one of them

is configured with no encryption and the other with WEP, is insecure. It can lead to

a compromise of the WEP key.
