A-78
ProCurve Wireless Services xl Module Command Line Reference
Wireless Commands
+phrase - Specify a passphrase from which the keys are to be derived.
-LINE - The passphrase between 4 and 32 characters long.
+web-default-key - Configures the transmit key index.
-<1-4>- The key index to be used for transmission from AP to MU.
Default Setting
Disabled
Command Mode
Wireless Configuration
Example
Related Commands
show wireless wlan-statistics (page A-126)
ProCurve(wireless-services-B)#configure
ProCurve(wireless-services-B)(config)#wireless
ProCurve(wireless-services-B)(config-wireless)#wlan 1 enable
ProCurve(wireless-services-B)(config-wireless)#wlan 1 ssid
SAM
ProCurve(wireless-services-B)(config-wireless)#wlan 1
encryption-type wep128
ProCurve(wireless-services-B)(config-wireless)#wlan 1
authentication-type eap
ProCurve(wireless-services-B)(config-wireless)#wlan 1
closed-system
ProCurve(wireless-services-B)(config-wireless)#wlan 1 qos
svp enable
ProCurve(wireless-services-B)(config-wireless)#wlan 1 inter-
station-blocking
ProCurve(wireless-services-B)(config-wireless)#wlan 1 wep128
wep-default-key 4
ProCurve(wireless-services-B)(config-wireless)
