A-83
ProCurve Wireless Services xl Module Command Line Reference
Show Commands (All Contexts)
Show Commands (All Contexts)
This section details the show commands displayed in all available contexts.
show alarm-log
This command displays all alarms since the last boot.
Syntax
show alarm-log (<1-65535> | acknowledged | all | new |)
• <1-65535> - Display details for specific alarm id.
• acknowledged - Display acknowledged alarms since boot.
• all - Display all alarms occurred since boot.
• new - Display new alarms occurred since boot.
Default Setting
N/A
Command Mode
All
Example
ProCurve(wireless-services-B)#show alarm-log
ProCurve Switch 5304XL(wireless-services-B)#sho alarm-log
Index: 2 Severity: normal Type: dhcpIPChanged Timestamp:
Apr 30 02:17:15 2006
Message: Interface: vlan1, New IP: [10.20.12.4/20]
Module: nsm Status: Unacknowledged
Index: 1 Severity: major Type: coldstart Timestamp: Apr
30 02:17:15 2006
Message: None
Module: snmp Status: Unacknowledged
ProCurve Switch 5304XL(wireless-services-
B)#ProCurve(wireless-services-B)#
