A-86
ProCurve Wireless Services xl Module Command Line Reference
Show Commands (All Contexts)
Example
show file
This command displays filesystem information.
Syntax
show file (information | systems |)
• information - Display file information.
– FILE - Display information on file.
• systems - Display filesystems.
Default Setting
N/A
Command Mode
Manager
Example
ProCurve(wireless-services-B)#show debug
debugging is off
ProCurve(wireless-services-B)#
ProCurve(wireless-services-B)#show file information TESTFILE
flash:TESTFILE:
type is text file
ProCurve(wireless-services-B)#
ProCurve(wireless-services-B)#show file systems
File Systems:
Size(b) Free(b) Type Prefix
- - opaque system:
4058112 2691072 flash nvram:
5057536 2764800 flash flash:
- - network tftp:
- - network ftp:
- - network scp:
ProCurve(wireless-services-B)#
