A-87
ProCurve Wireless Services xl Module Command Line Reference
Show Commands (All Contexts)
show flash
This command displays flash information.
Syntax
show flash
Default Setting
N/A
Command Mode
Manager
Example
show history
This command displays session command history.
Syntax
show history
Default Setting
N/A
Command Mode
Manager
ProCurve(wireless-services-B)#show flash
Image Build Date Install Date Version
----- -------------------- -------------------- --------------
Primary Nov 17 22:16:26 2005 Nov 22 15:18:17 2005 WS.01.XX.0551Swami
Secondary Nov 17 22:16:26 2005 Nov 21 13:10:07 2005 WS.01.XX.0551Swami
Current Boot : Primary
Next Boot : Primary
Software Fallback : Enabled
ProCurve(wireless-services-B)#
