A-89

ProCurve Wireless Services xl Module Command Line Reference

Show Commands (All Contexts)

Example

show ip

This command displays ip status and configuration.

Syntax

• arp - Display address resolution protocol.

• dns - Display dns nameservers.

• domain- Display default domain for dns.

• interface - Display ip interface status and configuration.

– IFNAME - Display vlan1-vlan4094.

ProCurve(wireless-services-B)#show interfaces

Interface dnlink

Hardware Type Ethernet, Interface Mode Layer 2, address is 00-01-e6-f5-86-fc

index 2 metric 1 mtu 1500 <UP,BROADCAST,RUNNING,MULTICAST>

Speed: Admin Auto, Operational 1g

Duplex: Admin Auto, Operational Full

input packets 2693, bytes 204774, dropped 0, multicast packets 0

input errors 0, length 0, overrun 0, CRC 0, frame 0, fifo 0, missed 0

output packets 0, bytes 0, dropped 0

output errors 0, aborted 0, carrier 0, fifo 0, heartbeat 0, window 0

collisions 0

Interface uplink

Hardware Type Ethernet, Interface Mode Layer 2, address is 00-01-e6-f5-86-fd

index 3 metric 1 mtu 1500 <UP,BROADCAST,RUNNING,MULTICAST>

Speed: Admin Auto, Operational 1g

Duplex: Admin Auto, Operational Full

input packets 3723, bytes 816128, dropped 0, multicast packets 2714

input errors 0, length 0, overrun 0, CRC 0, frame 0, fifo 0, missed 0

output packets 860, bytes 68860, dropped 0

output errors 0, aborted 0, carrier 0, fifo 0, heartbeat 0, window 0

collisions 0

Interface vlan1

Hardware Type VLAN, Interface Mode Layer 3, address is 00-01-e6-f5-86-fd

index 6 metric 1 mtu 1500 <UP,BROADCAST,RUNNING,MULTICAST>

inet 192.168.15.104/24 broadcast 192.168.15.255

input packets 2858, bytes 701077, dropped 0, multicast packets 0

input errors 0, length 0, overrun 0, CRC 0, frame 0, fifo 0, missed 0

output packets 6, bytes 1265, dropped 0

output errors 0, aborted 0, carrier 0, fifo 0, heartbeat 0, window 0

collisions 0

ProCurve(wireless-services-B)#
