A-90
ProCurve Wireless Services xl Module Command Line Reference
Show Commands (All Contexts)
• route - Display ip routing table.
• routing- Display ip routing status.
• web-management - Display web-server status.
Default Setting
N/A
Command Mode
Manager
Examples
ProCurve(wireless-services-B)#show ip arp
IP Address MAC Address Interface Type
192.168.15.1 00-14-bf-bf-72-30 vlan1 dynamic
ProCurve(wireless-services-B)# show ip dns
68.87.76.178 dynamic
68.87.66.196 dynamic
ProCurve(wireless-services-B)# show ip domain
IP dns-lookup : Enable
Domain Name : hsd1.ca.comcast.net.
ProCurve(wireless-services-B)# show ip interface vlan1
Interface IP-Address Status Protocol
vlan1 192.168.15.104(DHCP) up up
ProCurve(wireless-services-B)# show ip route
Codes: K - kernel/icmp, C - connected, S - static, D - DHCP
* - candidate default
Gateway of last resort is 192.168.15.1 to network 0.0.0.0
D* 0.0.0.0/0 [0/0] via 192.168.15.1, vlan1
C 192.168.15.0/24 is directly connected, vlan1
ProCurve(wireless-services-B)#show ip routing
IP routing is off
ProCurve(wireless-services-B)#show ip web-management
HTTP server status: enabled
ProCurve(wireless-services-B)#
