A-92
ProCurve Wireless Services xl Module Command Line Reference
Show Commands (All Contexts)
Example
show management
This command displays L3 management interface name.
Syntax
show management
Default Setting
N/A
Command Mode
Manager
Example
show password-encryption
This command displays password encryption parameters.
Syntax
show password-encryption (status)
• status - Displays password-encryption status.
Default Setting
N/A
ProCurve(wireless-services-B)#show logging
Syslog logging: enabled
Aggregation time: disabled
Console logging: level debugging
Monitor logging: disabled
Buffer logging: disabled
Trap logging: disabled
Log Buffer (0 bytes):
ProCurve(wireless-services-B)#
ProCurve(wireless-services-B)#show management
Mgmt Interface: vlan1
ProCurve(wireless-services-B)#
