A-93
ProCurve Wireless Services xl Module Command Line Reference
Show Commands (All Contexts)
Command Mode
Manager
Example
show redundancy-group
This command displays redundancy group parameters.
Syntax
show redundancy-group (config | runtime )
• config - Displays configured redundancy group information.
• runtime - Displays runtime redundancy group information.
Default Setting
N/A
Command Mode
Manager
Example: This example displays the redundancy group configuration.
ProCurve(wireless-services-B)#show password-encryption
status
Password encryption is enabled
ProCurve(wireless-services-B)#
ProCurve(wireless-services-B)#show redundancy-group config
Redundancy Group Configuration Detail
Redundancy Feature : Disabled
Redundancy group ID : 50
Redundancy Mode : Active
Redundancy Interface IP : 10.10.1.20
Number of configured peer(s) : 1
Heartbeat-period : 5 Seconds
Hold-period : 20 Seconds
Discovery-period : 10 Seconds
Handle STP : Enabled
Module Authorization Level : 36
ProCurve(wireless-services-B)#
