A-94

ProCurve Wireless Services xl Module Command Line Reference

Show Commands (All Contexts)

Examples: These examples display runtime and group information.

show redundancy-history

This command displays state transition history of the wireless module.

Syntax

show redundancy-history

Default Setting

N/A

ProCurve(wireless-services-B)#show redundancy-group runtime

Redundancy Group Runtime Information

Redundancy Protocol Version : 1.0

Redundancy Group Authorization Level : 0

Radio Ports Adopted by Group : Not Applicable

Radio Ports Adopted by this Module : Not Applicable

Redundancy State : Disabled

Established Peer(s) Count : Not Applicable

Redundancy Group Connectivity status : Not Applicable

ProCurve(wireless-services-B)#show redundancy-group

Redundancy Group Configuration Detail

Redundancy Feature : Disabled

Redundancy group ID : 50

Redundancy Mode : Active

Redundancy Interface IP : 10.10.1.20

Number of configured peer(s) : 1

Heartbeat-period : 5 Seconds

Hold-period : 20 Seconds

Discovery-period : 10 Seconds

Handle STP : Enabled

Module Authorization Level : 36
