A-97
ProCurve Wireless Services xl Module Command Line Reference
Show Commands (All Contexts)
Example
ProCurve(wireless-services-B)#show running-config
! configuration of ProCurveWLANModule Wireless Services version WS.01.03 on
Tue6
!
version 1.0
!
no country-code
redundancy group-id 50
redundancy interface-ip 10.10.1.20
redundancy holdtime-period 20
redundancy discovery-period 10
redundancy handle-stp enable
redundancy member-ip 10.10.1.21
ip web-management
snmp-server manager v2
snmp-server manager v3
snmp-server user manager v3 encrypted auth md5
0x709f649df8ba589f178416c291fcba0
snmp-server user operator v3 encrypted auth md5
0x777da3446d4dcea9e722cfaa520021
wireless
interface vlan1
ip address 192.168.1.5/21
!
end
ProCurve(wireless-services-B)#show running-config include-factory
! configuration of ProCurveWLANModule Wireless Services version WS.01.03 on
Tue6
!
version 1.0
!
no service password-encryption
no support prompt crash-info
no support set command-history
no support set reboot-history
no support set upgrade-history
hostname "Wireless Services"
ip dns-lookup
support pm max-sys-restarts 2
no support support pm sys-restart
support diag period 1000
support diag enable
no country-code
no snmp-server enable traps wireless-statistics min-packets
no snmp-server enable traps wireless-statistics wlan pktsps-greater-than
-- MORE --, next page: Space, next line: Enter, quit: Control-C
