A-101

ProCurve Wireless Services xl Module Command Line Reference

Show Commands (All Contexts)

Example

show terminal

This command displays terminal configuration parameters.

Syntax

show terminal

Default Setting

N/A

Command Mode

Manager

Example

ProCurve(wireless-services-B)#show startup-config

! factory default configuration

! prompt to include indication of crash files

support prompt crash-info

! vlan 1 gets an IP address via DHCP

interface vlan1

ip address dhcp

! web and snmp are enabled to allow the management java applet to function ip

web-management

snmp-server manager v2

snmp-server manager v3

snmp-server user manager v3 encrypted auth md5

0x709f649df8ba589f178416c291fcba0

snmp-server user operator v3 encrypted auth md5

0x777da3446d4dcea9e722cfaa520021

!ProCurve(wireless-services-B)#

ProCurve(wireless-services-B)#show terminal

Terminal Type: vt100

Length: 24 Width: 80

ProCurve(wireless-services-B)#
