A-105
ProCurve Wireless Services xl Module Command Line Reference
Show Commands (All Contexts)
Command Mode
Manager
Example
show vlans
This command displays vlan information.
Syntax
show vlans
ProCurve(wireless-services-B)#show version
ProCurveWLANModule version WS.01.XX.0551Swami
Copyright (c) 2005 Symbol Technologies, Inc.
Booted from primary.
Switch uptime is 0 days, 2 hours 37 minutes
CPU is AMD Athlon(tm) Processor
256112 kB of on-board RAM
ide device hda disk model TOSHIBA THNCF256MBA capacity 500736 blocks, cache 2
ProCurve(wireless-services-B)#show version verbose
ProCurveWLANModule version WS.01.XX.0551Swami
Copyright (c) 2005 Symbol Technologies, Inc.
Booted from primary.
Switch uptime is 0 days, 2 hours 42 minutes
CPU is AMD Athlon(tm) Processor
PCI bus 0 device 17 function 0
ISA bridge
VIA Technologies, Inc.
VT8235 ISA Bridge (rev 0).
PCI bus 0 device 17 function 1
IDE interface
VIA Technologies, Inc.
VT82C586A/B/VT82C686/A/B/VT823x/A/C PIPC Bus Master IDE (rev 6).
PCI bus 1 device 0 function 0
PIC
VIA Technologies, Inc.
VPX/VPX2 I/O APIC Interrupt Controller (rev 3).
PCI bus 2 device 8 function 0
Ethernet controller
Intel Corporation
82546EB Gigabit Ethernet Controller (rev 1).
-- MORE --, next page: Space, next line: Enter, quit: Control-C
