A-109

ProCurve Wireless Services xl Module Command Line Reference

Show Commands (Wireless)

Example

show wireless config

This command displays wireless configuration parameters.

Syntax

show wireless config

ProCurve(wireless-services-B)(config-wireless)#show wireless channel-power 11a

indoor

Channel Max Power (dBm) Radar Detected

36 (5180 MHz) 17 -

40 (5200 MHz) 17 -

44 (5220 MHz) 17 -

48 (5240 MHz) 17 -

52 (5260 MHz) 20 -

56 (5280 MHz) 20 -

60 (5300 MHz) 20 -

64 (5320 MHz) 20 -

149 (5745 MHz) 20 -

153 (5765 MHz) 20 -

157 (5785 MHz) 20 -

161 (5805 MHz) 20 -

165 (5825 MHz) 20 -

ProCurve(wireless-services-B)(config-wireless)#show wireless channel-power

11bg outdoor

Channel Max Power (dBm)

1 (2412 MHz) 20

2 (2417 MHz) 20

3 (2422 MHz) 20

4 (2427 MHz) 20

5 (2432 MHz) 20

6 (2437 MHz) 20

7 (2442 MHz) 20

8 (2447 MHz) 20

9 (2452 MHz) 20

10 (2457 MHz) 20

11 (2462 MHz) 20

ProCurve(wireless-services-B)(config-wireless)#
