A-110
ProCurve Wireless Services xl Module Command Line Reference
Show Commands (Wireless)
Default Setting
N/A
Command Mode
Manager Configuration Context
Global Configuration Context
Interface Configuration Context
Wireless Configuration Context
Example
show wireless ids
This command displays intrusion detection parameters.
Syntax
show wireless ids
Default Setting
N/A
Command Mode
Manager Configuration Context
Global Configuration Context
Interface Configuration Context
Wireless Configuration Context
ProCurve(wireless-services-B)(config-wireless)#show wireless config
country-code : us
adoption-pref-id : 1
proxy-arp : disabled
wlan-prioritization : disabled
adopt-unconf-radio : enabled
dot11-shared-key-auth: disabled
ap-detection : enabled
advanced-config : disabled
ProCurve(wireless-services-B)(config-wireless)#
