A-111
ProCurve Wireless Services xl Module Command Line Reference
Show Commands (Wireless)
Example
show wireless mac-auth-local entries
This command displays the mac-auth-local entries.
Syntax
show wireless mac-auth-local
Default Setting
N/A
Command Mode
Manager Configuration Context
Global Configuration Context
Interface Configuration Context
Wireless Configuration Context
show wireless phrase-to-key
This command displays the WEP keys generated by a passphrase.
Syntax
show wireless phrase-to-key (wep128 | wep64)
• wep128 - Displays WEP128 keys.
– WORD - Passphrase between 4 and 32 characters.
• wep64 - Displays WEP64 keys.
– WORD - Passphrase between 4 and 32 characters.
Default Setting
N/A
ProCurve(wireless-services-B)(config-wireless)#show wireless ids
filter-agetout : 60 seconds
excessive-probes : disabled
excessive-associations : disabled
ProCurve(wireless-services-B)(config-wireless)#
