A-118
ProCurve Wireless Services xl Module Command Line Reference
Show Commands (Wireless)
Example
show wireless rp-images
This command displays the radio-port images on the wireless module.
Syntax
show wireless rp-images
Default Setting
N/A
Command Mode
Manager Configuration Context
Global Configuration Context
Interface Configuration Context
Wireless Configuration Context
ProCurve(wireless-services-B)(config-wireless)#show wireless regulatory us
802.11a Outdoor
Channels : 52 56 60 64 149 153 157 161 165
Power(dBm): 20 20 20 20 20 20 20 20 20
802.11a Indoor
Channels : 36 40 44 48 52 56 60 64 149 153 157 161 165
Power(dBm): 17 17 17 17 20 20 20 20 20 20 20 20 20
802.11bg Outdoor
Channels : 1 2 3 4 5 6 7 8 9 10 11
Power(dBm): 20 20 20 20 20 20 20 20 20 20 20
802.11bg Indoor
Channels : 1 2 3 4 5 6 7 8 9 10 11
Power(dBm): 20 20 20 20 20 20 20 20 20 20 20
ProCurve(wireless-services-B)(config-wireless)#
