A-119
ProCurve Wireless Services xl Module Command Line Reference
Show Commands (Wireless)
Example
show wireless rp-status
This command displays the status of adopted radio-port.
Syntax
show wireless rp-status
Default Setting
N/A
Command Mode
Manager Configuration Context
Global Configuration Context
Interface Configuration Context
Wireless Configuration Context
Example
ProCurve(wireless-services-B)(config-wireless)#show wireless rp-images
Idx Image-File Version Release Date Size (bytes)
1 ProCurve-200-Series 00.02-27 [00] 04 Feb 2006 293320
ProCurve(wireless-services-B)(config-wireless)#
ProCurve(wireless-services-B)(config-wireless)#show wireless rp-status
Number of radio-ports : 2
rp1 00-14-C2-A0-0B-EC model: ProCurve Radio Port 220 serial: TW546WJ11E
bootloader: 0.4 sw-version: 2.0 fw-ver: 00.02-27 hw-ver: 17.0
num-radios: 2 [ 1 2 ]
rp2 00-14-C2-A0-1B-3E model: ProCurve Radio Port 230 serial: TW546WL12A
bootloader: 0.4 sw-version: 2.0 fw-ver: 00.02-27 hw-ver: 17.0
num-radios: 2 [ 3 4 ]
ProCurve(wireless-services-B)(config-wireless)#
