A-120
ProCurve Wireless Services xl Module Command Line Reference
Show Commands (Wireless)
show wireless rp-unadopted
This command displays a list of unadopted radio-port.
Syntax
show wireless rp-unadopted
Default Setting
N/A
Command Mode
Manager Configuration Context
Global Configuration Context
Interface Configuration Context
Wireless Configuration Context
Example
show wireless self-heal-config
This command displays the self-healing configuration parameters.
Syntax
show wireless self-heal-config
• self-heal-config - Details of self-heal parameters.
– <1-1000> - single radio index.
– all - all configured radios.
Default Setting
N/A
ProCurve(wireless-services-B)(config-wireless)#show wireless rp-unadopted
Idx radio-port Mac Last Seen
1] 00-14-C2-A0-1B-09 1 seconds ago
2] 00-14-C2-A0-0B-05 1 seconds ago
ProCurve(wireless-services-B)(config-wireless)#
