A-123
ProCurve Wireless Services xl Module Command Line Reference
Show Commands (Wireless)
show wireless web-auth-config
This command displays the WLAN web-auth configuration.
Syntax
show wireless web-auth-config
• web-auth-config - Wlan web-auth configuration.
– <1-32> - A WLAN index.
Default Setting
N/A
Command Mode
Manager Configuration Context
Global Configuration Context
Interface Configuration Context
Wireless Configuration Context
Example
ProCurve(wireless-services-B)(config-wireless)#show wireless web-auth-config
WLAN: 1 status: disabled description: ssid: SSID 1
Page-Location: internal
Radius Server Parameters:
primary server :
IP address: 0.0.0.0 authentication-port: 1812 radius-key:
secondary server :
IP address: 0.0.0.0 authentication-port: 1812 radius-key:
Retries: 3 Timeout: 5
Internal Pages
Page-type : login
Title : Login Page
Header : Network Login
Description : Please enter your username and password
Footer : Contact the network administrator if you do not have an account
Image URL main:
Image URL small:
-- MORE --, next page: Space, next line: Enter, quit: Control-C
