A-124
ProCurve Wireless Services xl Module Command Line Reference
Show Commands (Wireless)
show wireless wireless-module-statistics
This command displays the wireless module statistics.
Syntax
show wireless wireless-module-statistics
• wireless-module-statistics - wireless-module statistics.
– detail - detailed wireless-module statistics.
Default Setting
N/A
Command Mode
Manager Configuration Context
Global Configuration Context
Interface Configuration Context
Wireless Configuration Context
Example
ProCurve(wireless-services-B)(config-wireless)#show wireless wireless-module-
statistics
stations Associated : 0 Radios adopted : 4
------ Traffic -------------------------------------------------------
Total Rx Tx
---------------- ---------------- ----------------
30s 1hr 30s 1hr 30s 1hr
Pkts per sec: 0.00 0.00 0.00 0.00 0.00 0.00 pps
Throughput: 0.00 0.00 0.00 0.00 0.00 0.00
Mbps
Avg bit speed: 0.00 0.00 Mbps
% Non-unicast pkts: 0.00 0.00
------ RF Status------------------------------------------------------
------ Errors---------------------------------------------------------
-- MORE --, next page: Space, next line: Enter, quit: Control-C
