A-126

ProCurve Wireless Services xl Module Command Line Reference

Show Commands (Wireless)

Example

show wireless wlan-statistics

This command displays the WLAN statistics.

Syntax

show wireless wlan-statistics

ProCurve(wireless-services-B)(config-wireless)#show wireless wlan-config

# enabled ssid authentication encryption vlan description

1 Y Finance none wep128 1 Bldg-3-Finance

2 Y Employees eap aes 2 Bldg-2

3 N SSID 3 none none 1

4 N SSID 4 none none 1

5 N SSID 5 none none 1

6 N SSID 6 none none 1

7 N SSID 7 none none 1

8 Y Mngmnt eap tkip-aes 1 Bldg-1

9 N SSID 9 none none 1

10 N SSID 10 none none 1

11 N SSID 11 none none 1

12 N SSID 12 none none 1

13 N SSID 13 none none 1

14 N SSID 14 none none 1

15 N SSID 15 none none 1

16 N SSID 16 none none 1

17 N SSID 17 none none 1

18 N SSID 18 none none 1

19 N SSID 19 none none 1

20 N SSID 20 none none 1

21 N SSID 21 none none 1

22 N SSID 22 none none 1

23 N SSID 23 none none 1

24 N SSID 24 none none 1

25 N SSID 25 none none 1

26 N SSID 26 none none 1

27 N SSID 27 none none 1

28 N SSID 28 none none 1

29 N SSID 29 none none 1

30 N SSID 30 none none 1

31 N SSID 31 none none 1

32 N SSID 32 none none 1

ProCurve(wireless-services-B)(config-wireless)#
