A-128

ProCurve Wireless Services xl Module Command Line Reference

Show Commands (Wireless)

Example

ProCurve(wireless-services-B)(config-wireless)#show wireless wlan-statistics

***** WLAN-1 *********************

stations Associated : 1 Radios active : 2

------ Traffic -------------------------------------------------------

Total Rx Tx

---------------- ---------------- ----------------

30s 1hr 30s 1hr 30s 1hr

Pkts per sec: 0.00 27.34 0.00 0.00 0.00 27.34 pps

Throughput: 0.00 0.01 0.00 0.00 0.00 0.01

Mbps

Avg bit speed: 0.00 0.00 Mbps

% Non-unicast pkts: 0.00 100.00

------ RF Status------------------------------------------------------

30s 1hr

Avg station signal: 0.00 0.00 dBm

Avg station noise: 0.00 0.00 dBm

Avg station SNR(dB): 0.00 0.00

------ Errors---------------------------------------------------------

30s 1hr

Avg number of retries: 0.00 0.00

% gave up pkts: 0.00 0.00

% Non-decryptable pkts: 0.00 0.00
